Delivery trucks, semis, and heavy equipment back into loading docks thousands of times per year. The pit collects water and road salt. The apron edge takes constant steel-plate abuse. Standard concrete fails in five years. Portland Concrete engineers and builds docks to handle the actual loads, with proper slope, steel edge protection, and drainage that works. New construction or repair, we start with a free written estimate.
A parking lot spreads truck weight across a wide surface. A loading dock concentrates it. The rear wheels of a delivery truck land on the same 12-inch square of apron, thousands of times a year. Steel dock plates drag across the leading edge. Winter freeze-thaw cycles attack the pit where water pools. Concrete that performs for 30 years in a lot fails in five at a dock unless the slab is engineered thicker, reinforced heavier at the edge, and sloped to drain away from the pit instead of into it.
We build dock slabs with extra thickness, rebar placed to handle the concentrated wheel load, a steel edge angle cast into the leading edge to absorb dock-plate drag, and an apron slope that sheds water toward the parking lot or a catch basin. When an existing dock has failed, we diagnose whether the cause is localized edge spalling (repair with steel retrofit) or systemic undersizing (full replacement). Either way, the new concrete is engineered to the actual loads.
This same engineering discipline applies to our parking lot work, our commercial sidewalk projects, and the equipment pad slabs we pour. Each gets the right spec for its use.
Recent work
How it works
Building a Loading Dock Slab in Portland
Assess truck loads and site conditions
We measure the pit footprint, identify the truck types and weights that will use the dock, confirm whether a dock leveler will be installed, and plan the apron slope and drainage path.
Prepare pit and apron base
The pit is excavated to depth, the apron subgrade is compacted, gravel base is laid, and any pit drainage lines are run before forming begins.
Form, reinforce, embed steel
Pit walls and apron edges are formed to spec, rebar is tied with extra reinforcement at the wheel-load zone, the steel edge angle is positioned and welded to embed studs, and dock-leveler anchor bolts are set if needed.
Pour, slope, finish, harden
Concrete is placed and consolidated, the apron is finished with the correct slope away from the pit, the surface is troweled for grip, and a hardener is applied to high-wear zones.
When repair is the right answer
Fixing a Failed Loading Dock Means Finding the Root Cause
A spalled dock edge does not mean the whole slab failed. If the concrete beneath is sound and the edge damage is localized, we cut out the failed section, add reinforcement, cast a new edge with the steel angle, and the dock is restored. But if the original dock was engineered wrong from day one (too thin, no reinforcement, sloped into the pit instead of away), patching the edge is just delaying the next failure.
We assess every failed dock as an engineering problem first. Is the slab thickness adequate? Is the reinforcement in the right places? Does the slope drain away from the pit? Once we know the cause, we specify the repair that actually fixes it. Sometimes that is sectional replacement with proper reinforcement. Sometimes it is adding the steel edge angle that was missing. Sometimes it is the honest answer: a full dock replacement because the original was undersized everywhere. Our site concrete team applies the same logic to every commercial concrete project we touch.
Slab specs, steel edges, dock-leveler embeds, drainage and when to repair vs replace.
Because they take concentrated repeat loads at a single point (the truck rear-wheel landing spot), steel-on-concrete abuse from dock plates, and concentrated water/salt at the pit. A parking-lot spec slab fails inside five years at a loading dock; the dock spec is different by design.
It protects the leading edge of the dock from the steel dock plates that drag across it during loading. Without it, the concrete edge spalls within a year of regular dock-plate use. The angle is cast into the pour with embed studs that anchor it permanently.
Yes. We coordinate with the dock-leveler supplier to set their embeds (anchor bolts, channels) at the right positions before the pour. Adding them after the pour is messy and rarely fits as cleanly; integrating them up front is the right way.
Always away from the pit. The slope drains meltwater and rain off the apron toward the parking lot or a catch basin, never into the pit which catches enough water on its own from the open dock door. Reverse-sloping into the pit is the most common failed-dock pattern we see.
Depends on the cause. Localised spalling at the edge with a sound slab beneath, sectional repair plus a steel edge retrofit works. Systemic failure from wrong original engineering (too-thin apron, no reinforcement, reverse slope), a new dock is the honest answer.
